Modelling Soil-Structure-Interaction for Offshore Wind Energy Plants

Modelling Soil-Structure-Interaction for Offshore Wind Energy Plants

Prof. Dr.-Ing. Martin Achmus / Dr.-Ing. Khalid Abdel-Rahman / Dipl.-Ing. Florian tom Wörden

Fig.1: Horizontal displacement of monopile foundation embedded in medium dense sand (H=8.0 MN, M= 240.0 MNm) Fig.1: Horizontal displacement of monopile foundation embedded in medium dense sand (H=8.0 MN, M= 240.0 MNm) Fig.1: Horizontal displacement of monopile foundation embedded in medium dense sand (H=8.0 MN, M= 240.0 MNm)
Fig.1: Horizontal displacement of monopile foundation embedded in medium dense sand (H=8.0 MN, M= 240.0 MNm)

The foundation of offshore wind plants (OWEP) especially in the North Sea with water depths up to 30 m represent a technical challenge. In order to find an economical solution, the exact investigation of the structure's behaviour, particularly the long-term behaviour under cyclic loading from wave and wind should be studied. In this project numerical models will be developed to investigate the behaviour of the foundation of offshore wind plants based on modern studies related to the behaviour of soil under quasi-static or dynamic cyclic loading taking into account the interaction between the soil and the different types of foundation systems. Numerical models for the different foundation types (Gravity foundation, Monopile foundation, Tripod foundation) have been developed (Fig. 1).



A substantial aspect of this project is the realistic description of the soil behaviour under the repeated loading caused by waves and wind. A suitable material model is to be formulated and implemented by means of appropriate numeric algorithms into the program system ABAQUS. Further model developments are required to illustrate the behaviour of the soil and of the foundation system used under dynamic load.
